Brass Inverted Flare Connector, 3/8 X 1/4 In., Model 54348-0604

Overview: The Anderson Metals Brass Inverted Flare Connector is a high-quality, durable fitting designed for use with various types of tubing including copper, brass, aluminum, and steel. This connector is ideal for applications involving liquids, gases, and hydraulic brake systems, making it a versatile choice for both professional and DIY projects.

Key Features:
- Two Piece Construction: Features a nut and body for enhanced reliability.
- Compatibility: Suitable for use with copper, brass, aluminum, or steel tubing.
- Temperature Range: Operates effectively in temperatures ranging from negative 65 degrees Fahrenheit to plus 250 degrees Fahrenheit.
- Recessed Seats and Threads: Protects critical components from damage and wear.
- Compact Design: Shorter overall length makes it perfect for limited space applications.
- Flexible Installation: Shorter nut allows tubing to be bent closer to the fitting for easier installation.
- Vibration Resistance: Fair resistance to vibrations ensures a secure connection.
- Mechanical Pullout Resistance: Designed to resist mechanical pullout for added safety.
- Reusable: Easy to disassemble and can be reassembled multiple times without affecting the seal.
- Primary Uses: Ideal for liquids, gases, and hydraulic brake systems.

Assembly Instructions:
1. Cut a smooth, square end on the tubing.
2. Slide the nut onto the tube with threads facing the end.
3. Flare the end of the tube.
4. Thread the nut onto the body until snug, then turn an additional one-sixth of a turn.

This connector is perfect for a variety of plumbing and fuel equipment applications, ensuring a reliable and leak-free connection every time.
